Find Parts by Vehicle

GuideUpdated 2026-07-10

Repco is the one supplier where you can shop by vehicle. Pick a vehicle through a Make → Model → Year → Series → Engine → Variant cascade, see every compatible part, and turn that list into a running collection in a single call. See Vehicles & Fitment for the concepts behind this.

In the dashboard

Open Suppliers → Repco → Vehicles from the sidebar.
Work down the cascade selectors — Make, then Model, Year, Series, Engine, and finally Variant. Each selector loads its options from the one before it.
When you pick a variant, the compatible parts load in a table (title, brand, price, freight).
Click Scrape this vehicle's parts to create a collection of every compatible part.
Switch to Reverse lookup to go the other way — enter a product code and see which vehicles it fits.

Repco Vehicles page with a make-to-variant cascade and a table of compatible parts — Work down the cascade to a variant; the compatible parts load automatically.

Via the API

Step 1 — Cascade to a vehicle

Vehicle Cascade

POST

https://multicartapi.com/api/v1/schedules/repco/vehicles/cascade/

API Key or Session Token

Send the levels you have chosen so far; the response returns the options for the next unfilled level. Start with an empty body to get the list of makes, then add one level at a time until you reach a variant (which carries the vehicle_code).

Parameter	In	Type	Required	Default	Description
`make`	body	string	Optional	—	Selected make, e.g. `FORD`.
`model`	body	string	Optional	—	Selected model, e.g. `FALCON`.
`year`	body	integer	Optional	—	Selected year, e.g. `2016` (matched against each vehicle's year range).
`series`	body	string	Optional	—	Selected series, e.g. `FG X`.
`engine`	body	string	Optional	—	Selected engine, e.g. `4.0L 6cyl`.

# First call — no selection, returns the list of makes
curl https://multicartapi.com/api/v1/schedules/repco/vehicles/cascade/ \
-X POST \
-H "x-api-key: YOUR_API_KEY" \
-H "Content-Type: application/json" \
-d '{}'

# Later call — full selection, returns the variant leaf with the vehicle_code
curl https://multicartapi.com/api/v1/schedules/repco/vehicles/cascade/ \
-X POST \
-H "x-api-key: YOUR_API_KEY" \
-H "Content-Type: application/json" \
-d '{ "make": "FORD", "model": "FALCON", "year": 2016, "series": "FG X", "engine": "4.0L 6cyl" }'

Response

{
"code": 200,
"data": {
  "level": "variant",
  "options": [
    { "vehicle_code": "65740", "variant": "XR6", "year_range": "2014-2016" }
  ],
  "count": 1
},
"status": 1
}

What each level returns

For make, model, series, and engine the options are plain strings. For year they are integers (newest first). For variant each option is an object carrying the vehicle_code you use in the next steps.

Step 2 — See compatible parts

Fitment Search (Vehicle → Parts)

POST

https://multicartapi.com/api/v1/schedules/repco/fitment/search/

API Key or Session Token

Parameter	In	Type	Required	Default	Description
`vehicle_code`	body	string	Required	—	The vehicle code from the cascade, e.g. `65740`.
`page`	body	integer	Optional	1	1-indexed page number.
`page_size`	body	integer	Optional	50	Parts per page. Range 1–200.

curl https://multicartapi.com/api/v1/schedules/repco/fitment/search/ \
-X POST \
-H "x-api-key: YOUR_API_KEY" \
-H "Content-Type: application/json" \
-d '{ "vehicle_code": "65740", "page": 1, "page_size": 50 }'

Response

{
"code": 200,
"data": {
  "vehicle": {
    "vehicle_code": "65740",
    "make": "FORD", "model": "FALCON", "series": "FG X",
    "engine": "4.0L 6cyl", "variant": "XR6", "year_range": "2014-2016",
    "swept": true, "part_count": 542
  },
  "total": 542,
  "page": 1,
  "page_size": 50,
  "total_pages": 11,
  "parts": [
    {
      "product_code": "A1547402",
      "notes": "",
      "universal": false,
      "in_catalog": true,
      "title": "Ryco Oil Filter Z516",
      "brand": "Ryco",
      "price_value": 18.99,
      "freight_value": 0.0,
      "image": "https://www.repco.com.au/...jpg",
      "url": "https://www.repco.com.au/en/p/...A1547402"
    }
  ]
},
"status": 1
}

The swept flag

vehicle.swept tells you whether this vehicle has already been indexed. An un-swept vehicle returns total: 0 — that does not mean "no compatible parts", only that it has not been crawled yet. You can still create a collection for it (next step); MCA fetches the parts live at that point.

Reverse lookup — which vehicles does a part fit?

Fitment Reverse (Part → Vehicles)

POST

https://multicartapi.com/api/v1/schedules/repco/fitment/reverse/

API Key or Session Token

Parameter	In	Type	Required	Default	Description
`product_code`	body	string	Required	—	The part's product code, e.g. `A1547402`.
`page`	body	integer	Optional	1	1-indexed page number.
`page_size`	body	integer	Optional	50	Vehicles per page. Range 1–200.

Response

{
"code": 200,
"data": {
  "product_code": "A1547402",
  "total": 64,
  "page": 1,
  "page_size": 50,
  "total_pages": 2,
  "vehicles": [
    {
      "vehicle_code": "65740",
      "make": "FORD", "model": "FALCON", "series": "FG X",
      "engine": "4.0L 6cyl", "variant": "XR6", "year_range": "2014-2016",
      "notes": ""
    }
  ]
},
"status": 1
}

Step 3 — Scrape every part that fits

Turn a vehicle into a running collection of all its compatible parts in one call.

Create Collection from Fitment

POST

https://multicartapi.com/api/v1/schedules/repco/fitment/create_collection/

API Key or Session Token

Parameter	In	Type	Required	Default	Description
`vehicle_code`	body	string	Required	—	The vehicle code to build the collection from.
`customer_postcode`	body	string	Required	—	Postcode value or Zipcode row ID. Freight and price are captured live here when the collection runs.
`name`	body	string	Optional	—	Collection name. Defaults to `"{make} {model} {year_range} — fitment"`.

curl https://multicartapi.com/api/v1/schedules/repco/fitment/create_collection/ \
-X POST \
-H "x-api-key: YOUR_API_KEY" \
-H "Content-Type: application/json" \
-d '{
  "vehicle_code": "65740",
  "customer_postcode": "4500",
  "name": "FG X Falcon parts"
}'

Response

{
"code": 200,
"data": {
  "collection_id": 42110,
  "name": "FG X Falcon parts",
  "vehicle_code": "65740",
  "product_count": 542,
  "applied_cap": false
},
"status": 1
}

This spends credits and works even before a sweep

Creating a fitment collection charges 1 credit per part. If the vehicle has not been indexed yet, MCA runs the vehicle lookup live on the spot and persists it — so the call works for any vehicle, not only pre-swept ones. An unknown vehicle_code returns code 404; if Repco blocks the live lookup you get code 503 (retry shortly); if no parts are found, code 400; if your balance is too low, code 402.
